LEDVANCE NAV 100 LED FILAMENT AMBER V 3200LM 30W 718 E40

NEW

Preview: LEDVANCE NAV 100 LED-FILAMENT LICHTQUELLE GELB V 3200LM 30W 718 E40

LEDVANCE NAV 100 LED-FILAMENT LICHTQUELLE GELB V 3200LM 30W 718 E40

€29.52 *

incl. tax, plus shipping costs

Availability:

Delivery time: approx. 2-3 weeks

Delivery time: approx. 2-3 weeks

Item number: 101420330

EAN: 4058075843622

MPN: 4058075843622

NEW

LEDVANCE NAV 100 LED FILAMENT AMBER V 3200LM 30W 718 E40 product advantages Support the... more

Back to the overview

All information about the product:

"LEDVANCE NAV 100 LED FILAMENT AMBER V 3200LM 30W 718 E40"

LEDVANCE NAV 100 LED FILAMENT AMBER V 3200LM 30W 718 E40

product advantages

Support the protection of wildlife thanks to reduced blue light
Contribution to improving the quality of life of residents by supporting the natural day-night rhythm
Better color rendering and improved visibility compared to traditional sodium vapor lamps (NAV)
Same design as traditional NAV lamps with tubular, clear solid glass bulb
Full utilization of the reflector of the existing luminaire thanks to 360 degree beam angle
Saves up to 70% energy when used as a replacement for sodium vapor lamps (NAV)
Immediate 100% light, no warm-up time
Similar light distribution to traditional NAV lamps

Areas of application

Street and outdoor lighting
Areas close to nature
residential areas
park facilities
Historic buildings and neighborhoods
Outdoor applications only in suitable luminaires

product features

Less than 1.5% blue light content (
Very warm light color of 1800 K, similar to traditional sodium vapor lamps (NAV)
Suitable for operation with conventional ballasts (CCG, VVG) or 230 V mains voltage
Power factor: 0.9
Protection class: IP65
Overvoltage protection: up to 2 kV (L-N)

safety instructions

Not suitable for use with ignition devices.
Operation at the condenser can lead to a reduction in the power factor of the system.
When installed horizontally, the tc point of the lamp is located on the top of the lamp.
Only suitable for temperatures up to 50 °C inside the luminaire. Not recommended for use in luminaires with close-fitting reflectors or in narrow luminaires.
All electrical connections must only be carried out by qualified personnel.
Not suitable for room lighting in the home.
Do not touch the lamp if it is damaged.

Technical data:

Length:	225 mm
Width:	46 mm
Height:	46 mm
Diameter:	46 mm
Weight:	170 g
Socket:	E40
Nominal voltage:	220-240 V
Nominal power:	30 W
Nominal current:	125 mA
Energy consumption:	30 kWh/1000
Colour temperature:	1800 K
Light colour:	Warm white
Beam angle:	360°
Luminous flux:	3200 lm
Luminous efficacy:	106 lm/W
Colour rendering:	70-79 CRI
Dimmable:	No
Lifetime:	25000 h
Switching cycles:	100000
Protection class:	IP65
Power factor:	0.90
Voltage type:	AC
Suitable for electronic ballast:	no
Suitable for magnetic ballast:	yes
Filament lamp:	yes
Type of glass/cover:	Clear
Colour consistency (McAdam ellipse):	SDCM6
Dimming phase cut-off (trailing edge):	no
Dimming phase cut-on (leading edge):	no
Dimming Touch and Dim:	no
Dimming Zigbee:	no
Dimming Bluetooth:	no
Dimming Wi-Fi:	no
Total harmonic distortion:	30
Remote operation possible:	no
With movement sensor:	no
With remote control:	no
With twilight switch:	no
Photobiological safety according to EN 62471:	RG1
Compatible with Apple HomeKit:	no
Compatible with Google Assistant:	no
Compatible with Amazon Alexa:	no
IFTTT support available:	yes
