Osram LED TUBE T8 EM S 1500 mm 17.7W 840
€12.15 *
incl. tax,
plus shipping costs
Express delivery possible
Availability:
Delivery time: 3-5 days
Delivery time: approx. 3-5 days
Item number: 100231700
EAN: 4099854037658
MPN: 02-037658
Product benefits
No bending thanks to glass technology
Shatter protection thanks... more
All information about the product:
"Osram LED TUBE T8 EM S 1500 mm 17.7W 840"
Product benefits
- No bending thanks to glass technology
- Shatter protection thanks to special PET coating
- Support the implementation of the HACCP concepts from production through to presentation
- Very high resistance to switching loads
- Quick, simple and safe replacement without rewiring
- Energy savings of up to 70 % (compared to T8 fluorescent lamp)
- Instant-on light, therefore ideally suitable in combination with sensor technology
- Also suitable for operation at low temperatures
Technical Data |
|
| Electrical data | |
| Nominal wattage | 17.7 W |
| Construction wattage | 17.70 W |
| Nominal voltage | 220…240 V |
| Operating mode | CCG, AC Mains |
| Nominal current | 80 mA |
| Type of current | AC |
| Inrush current | 4.68 A |
| Suitable for DC input | Yes |
| Input voltage DC | 186…260 V |
| Operating frequency | 50/60 Hz |
| Mains frequency | 50/60 Hz |
| Max. lamp no. on circuit break. 10 A (B) | 98 |
| Max. lamp no. on circuit break. B10 A - CCG without compensation | 65 |
| Max. lamp no. on circuit break. B10 A - CCG with compensation | 21 |
| Max. lamp no. on circuit break. 16 A (B) | 129 |
| Max. lamp no. on circuit break. B16 A - CCG without compensation | 84 |
| Max. lamp no. on circuit break. B16 A - CCG with compensation | 28 |
| Total harmonic distortion | < 20 % |
| Power factor λ | 0.90 |
| Photometrical data | |
| Luminous flux | 3100 lm |
| Luminous efficacy | 175 lm/W |
| Lumen main.fact.at end of nom.life time | 0.70 |
| Light color (designation) | Cool White |
| Color temperature | 4000 K |
| Color rendering index Ra | 80 |
| Light color | 840 |
| Standard deviation of color matching | ≤5 sdcm |
| Rated LLMF at 6,000 h | 0.80 |
| Flickering metric (Pst LM) | 1 |
| Stroboscope effect metric (SVM) | 0.4 |
| Light technical data | |
| Beam angle | 190 ° |
| Warm-up time (60 %) | ‹ 0.50 s |
| Starting time | < 0.5 s |
| Dimensions & Weight | |
| Overall length | 1513.00 mm |
| Length with base excl. base pins/connection | 1500.00 mm |
| Diameter | 26.70 mm |
| Tube diameter | 25.8 mm |
| Maximum diameter | 27 mm |
| Product weight | 242.00 g |
| Temperatures & operating conditions | |
| Ambient temperature range | -20…+50 °C |
| Maximum temperature at tc test point | 70 °C |
| Lifespan | |
| Lifespan L70/B50 at 25 °C | 75000 h |
| Number of switching cycles | 200000 |
| Lumen maintenance at end of service lifetime | 0.70 |
| Rated lamp survival factor at 6,000 h | ≥ 0.90 |
| Additional product data | |
| Base (standard designation) | G13 |
| Mercury content | 0.0 mg |
| Mercury-free | Yes |
| Capabilities | |
| Dimmable | No |
| Certificates & Standards | |
| Energy efficiency class | C 1) |
| Energy consumption | 18.00 kWh/1000h |
| Type of protection | IP20 |
| Standards | CE, UKCA, VDE, ENEC, EAC |
| Photobiological safety group acc. to EN62778 | RG0 |
| Country-specific categorizations | |
| Order reference | LEDTUBE T8 EM S |
| LOGISTICAL DATA | |
| Temperature range at storage | -20…+80 °C |
| Energy labelling regulation data acc EU 2019/2015 | |
| Lighting technology used | LED |
| Non-directional or directional | NDLS |
| Mains or non-mains | MLS |
| Light source cap-type (or other electric interface) | G13 |
| Connected light source (CLS) | No |
| Color-tuneable light source | No |
| Envelope | No |
| High luminance light source | No |
| Anti-glare shield | No |
| Correlated colour temperature type | SINGLE_VALUE |
| Standby power | <0.5 W |
| Claim of equivalent power | No |
| Length | 1513.00 mm |
| Height | 26.70 mm |
| Width | 26.70 mm |
| Chromaticity coordinate x | 0.3818 |
| Chromaticity coordinate y | 0.3797 |
| R9 Colour rendering index | 0.00 |
| Beam angle correspondence | SPHERE_360 |
| Survival factor | 0.9 |
| Displacement factor | 0.9 |
| LED light source replaces a fluorescent light source | No |
| EPREL ID | 1334043,1529738 |
| Model number | AC45356,AC51566 |
