LEDVANCE DP S 1500 26W 840 IP65 GY

NEW

€57.09 *

incl. tax, plus shipping costs

Availability:

Delivery time: approx. 2-3 weeks

Delivery time: approx. 2-3 weeks

Item number: 101418730

EAN: 4058075836082

MPN: 4058075836082

NEW

LEDVANCE DP S 1500 26W 840 IP65 GY product advantages Installation of a large number of... more

Back to the overview

All information about the product:

"LEDVANCE DP S 1500 26W 840 IP65 GY"

LEDVANCE DP S 1500 26W 840 IP65 GY

product advantages

Installation of a large number of sensor-controlled luminaires possible thanks to master-slave and master-master functionality
Multiple settings for sensor range, daylight detection, and hold time
Low flicker = 10%
Easy installation, tool-free connection
5-year warranty

Areas of application

Industrial and storage areas
Parking spaces and underpasses
garages
Workshops, production lines

product features

High-frequency sensor for daylight and motion detection
Sensor with master-slave and master-master functionality
High light output: up to 139 lm/W
Beam angle: 110°

Technical equipment

Retaining bracket, theft protection, suspension bracket, second cable gland and 2 throttle nipples included

References / References

For warranty information, please visit www.ledvance.de/garantie.

Technical data:

Length:	1500 mm
Width:	82 mm
Height:	68 mm
Weight:	1715 g
Nominal voltage:	220-240 V
Nominal power:	26 W
Nominal current:	125 mA
Energy consumption:	26 kWh/1000
Colour temperature:	4000 K
Light colour:	White
Beam angle:	110°
Luminous flux:	3500 lm
Luminous efficacy:	135 lm/W
Colour rendering:	80-89 CRI
Dimmable:	No
Lifetime:	70000 h
Switching cycles:	100000
Protection class:	IP65
Light source type:	LED not exchangeable
Material:	Plastic
Colour:	Grey
Incl. illuminant:	Yes
Suitable for wall mounting:	yes
Suitable for suspended mounting:	yes
Suitable for ceiling mounting:	yes
Suitable for built-in mounting:	no
Suitable for surface mounting:	yes
Suitable for light line configuration:	no
Suitable for workplace according to EN 12464-1:	no
Surface protection housing:	Untreated
Material cover:	Plastic, opal
Voltage type:	AC
Type of control gear:	Electronic ballast
With control gear:	yes
Exchangeable control gear:	yes
Dimming phase cut-off (trailing edge):	no
Dimming phase cut-on (leading edge):	no
Dimming Touch and Dim:	no
Dimming Zigbee:	no
Light distributor:	Diffuser lens/optic/panel
Light outlet:	Direct
Max. number of luminaires per miniature circuit breaker B16 (MCB):	56
Max. number of luminaires per miniature circuit breaker C16 (MCB):	44
Impact strength:	IK08
Protection class according to IEC 61140:	I
Rated ambient temperature according to IEC 62722-2-1:	+40°C
Suitable for emergency lighting:	no
Emergency power supply integrated:	no
With movement sensor:	yes
With light sensor:	yes
Covering of the luminaire with thermally insulating material possible:	no
With air slots:	no
Power factor:	0.90
Constant light output (CLO):	no
Type of wiring:	Suitable for loop-through wiring
Number of poles:	5
Connection type:	Push-in clamp
Photobiological safety according to EN 62471:	RG0
Colour of light adjustable:	No
Luminous flux adjustable:	No
Beam angle adjustable:	No
Operation by Bluetooth:	no
Compatible with Casambi:	no
Compatible with Apple HomeKit:	no
Compatible with Google Assistant:	no
Compatible with Amazon Alexa:	no
IFTTT support available:	yes
Meets min. EIA lifetime criterion L90 (at 50,000 hours at tq = 25 °C):	no
